LED Zoom Wash 37x15W Moving Head

LED Zoom Wash 37x15W Moving Head is a versatile wash fixture featuring 37x15W RGBW LEDs, offering smooth color mixing and a motorized zoom range from 4° to 45°. It delivers both narrow beam looks and soft wash effects, making it suitable for concerts, clubs, and stage applications.

This 37x15W moving head includes creative ring control effects, allowing segmented LED zones to produce dynamic visuals and eye-catching chases. Compact and reliable, this LED zoom wash is a solid choice for designers seeking flexible effects in a mid-range fixture.

Model: WZ3715

Description

Description

Product Video – LED Wash 37x15W Moving Head

Technical Specifications

• Light Source: 37x15W RGBW LED
• Input Voltage: AC100~240V, 50/60 Hz
• Zoom Range: 4 – 45°
• Power Consumption: 800W
• Control Mode: DMX512, master-slave, auto-run, sound, RDM
• DMX Channel: 16/36 CH
• Features: Beam, wash, zoom, circle control effect, built-in macro function
• Dimming: 0~100% linear dimming
• Pan/Tilt: 540°/270° (16 bit)
• Strobe Frequency: 1~25 Hz
• DMX input/output: 3-pin XLR Head Socket
• Power Socket: PowerCon in/out
• Display: LCD
• Protection Rating: IP20
• Net Weight: 13 kg
