12x40W Pixel Beam Moving LED Bar with Zoom

Bring dynamic creativity to any stage with our 12x40W moving LED bar with zoom, a high-performance moving LED bar that integrates powerful beam effects, pure and even washes, and dynamic pixel control for versatile stage lighting. This professional moving LED bar is equipped with 12x40W RGBW 4-in-1 LEDs and 144×0.3W RGB 5050 background LEDs, delivering bright foreground lighting and vibrant ambient backlight for stunning visual layers.

Thanks to its motorized zoom range of 5°–45°, the moving LED bar can easily switch between narrow beams and wide washes. With 220° tilt movement, full pixel control, and built-in macro effects, it offers flexible design options for concerts, stages, and creative lighting setups. Whether used as a pixel beam bar or a wash light, this fixture brings exceptional versatility to any show.

Model: BWZ1240R

Description

Product Video – 12X40W Pixel Beam Moving Head LED Bar with Zoom



Technical Specifications

• Light Source:
12x40W RGBW 4in1 LEDs
144×0.3W RGB 5050 3in1 background LEDs
• Input Voltage: AC100~240V, 50/60 Hz
• Zoom Range: 5 -45°
• Power Consumption: 500W
• Control Mode: DMX512, master-slave, auto-run, sound, RDM
• DMX Channel: 24/144 CH
• Features: Beam, wash, zoom, LED pixel control, built-in macro function program
• Dimming: 0~100% linear dimming
• Tilt: 220° (16 bit)
• Strobe Frequency: 1~25 Hz
• Data Socket: 3-pin XLR in/out
• Power Socket: PowerCon in/out
• Display: 1.7-inch LCD
• Protection Rating: IP20
• Net Weight: 14.5 kg
